1986 Chevy 10-30 Series LD Truck Wiring Diagrams - 11x26 inch Foldouts

  • Sale
  • Regular price $36.00


This 1986 Chevy 10-30 Series LD Truck Wiring Diagrams - 11x26 inch Foldouts is a high-quality, licensed PRINT reproduction of the service manual authored by Chevrolet Motor Division and published by Detroit Iron. This new print manual is reproduced using the highest quality digital print equipment available - shrink wrapped and ready to be shipped to your location. This OEM factory manual is 8.5 x 11 inches, paperback stitched, shrink-wrapped and contains 40 of 11x26 inch foldout detailed factory wiring diagrams. Wiring Diagrams were originally written by the automotive manufacturer to be used by their dealership mechanics.

YEAR(S), MAKE(S) & MODEL(S) COVERED:

  • 1986 Chevrolet MODELS COVERED: C10, C10 Suburban, C20, C20 Suburban, C30, K10, K10 Suburban, K20, K20 Suburban, K30, K5 Blazer, G10, G20, G30, P20, P30

With the 1986 Chevy 10-30 Series LD Truck Wiring Diagrams - 11x26 inch Foldouts in your toolbox, you have the most comprehensive literature at your fingertips to take on the most challenging repair, service and restoration projects. This factory-written Detroit Iron shop manual is perfect for the restorer or anyone working on one of these vehicles.

MANUAL SPECIFICATIONS:
OEM Part Number: ST-330-86 WD
Binding: Paperback - 8.5 x 11 x 0.08 inches
Pages: 40 - Hundreds of b&w illustrations
Author: Chevrolet Motor Division
Publisher: Detroit Iron
Paper: 50# Paper Acid & Clorine Free, FSC (Forest Stewardship Council) Certified, Rainforest Alliance Certified
